Mosfet II - JeffTron

SPECIFICATIONS: - Standalone device without cables, for power circuit cables with a maximum cross-section of 1.5 mm² and for signal cables with a maximum cross-section of 0.5 mm² can be used cables with a max. cross-section of 1.5 mm²  and for signal cables with a max. cross-section of 0.5 mm² - Suitable for service centers; if you are unsure about soldering wires to the board, choose the version with cabling and accessories. - Designed for springs up to M210 (corresponds to a current of 150A for a single shot or 50A for burst firing for a maximum of 30s) - Designed for all types of commonly used batteries up to 17 V (Ni-xx 8.4 - 12V, lipol 7.4 - 14.8V) - 6-wire connection - Device size 25x12x7mm - Trigger contacts do not burn - No current is drawn in idle state - Due to the principle of operation of the AEG weapon mechanism, the piston stops in a random position in AUTO mode - For this device to function properly, the gearbox must have a functional interrupter, switch mechanism, reverse latch, trigger, and trigger stop (locked), i.e., as in a standard gearbox
